The 322 Thermal Overload Relay-C&S LR1-D25, manufactured by C&S Controls & Switchgear Contactors Ltd., is engineered to provide robust overload protection for electrical systems. Designed for industrial applications, this relay ensures the safety and efficient operation of your machinery. With its reliable performance, the 322 Thermal Overload Relay is a crucial component for safeguarding against electrical faults.
This relay offers an ITH of 95N.C. and 96 10A 98N.O., adhering to IEC standards 292 and 947, as well as IS standard 13947. Featuring a UI rating of 660V~, it can manage a maximum fuse size of 50A according to IS standard 9224. It is suitable for use with 480V AC max class 10 withstand current of 5000A RMS symmetrical. The relay supports a maximum fuse size of 100A with an AWG rating of 10-18cu75°C, ensuring broad compatibility. The torque required for installation is 15lb.in. This non-time delay relay features TC B600 NO98-97 NC 95 96 configuration.
Key Features:
Specifications:
Ensure the longevity and safety of your electrical systems with the 322 Thermal Overload Relay-C&S LR1-D25. Its robust design and compliance with industry standards make it an ideal choice for various industrial and automation applications. Trust in the reliability of C&S Controls for superior performance. For your industrial automation components needs, contact Ram Automations at info@ramautomations.com.
