Mitsubishi NF125-SV 3P 100A 690V Circuit Breaker – Industrial Grade

SKU: RAMA44613
Product type: Electrical Components > Circuit Breakers > Industrial Breakers
$999.00
In Stock
Order soon or ask us about restock timing.

Need More Details?

If you'd like to check stock availability, request the latest price, or view more product images, simply click the "Request for Price" button and our team will assist you promptly.

WhatsApp

Related Search: 690V, circuit breaker, electrical protection, industrial automation, Mitsubishi, NF125-SV, no-fuse breaker

OEM-Verified Parts
15+ Years Experience
Worldwide Shipping
Marine & Offshore Ready

The Mitsubishi NF125-SV 3P 100A 690V circuit breaker is a vital component for safeguarding electrical systems in industrial applications. This no-fuse breaker, manufactured by Mitsubishi Electric Corporation, is engineered for reliable performance and protection. Designed for use with AC 200V systems, it boasts a robust breaking capacity of 50kA, ensuring rapid response to overcurrents and short circuits. Ideal for various electrical setups operating at 50/60Hz, this circuit breaker offers dependable protection for your valuable equipment.

This circuit breaker adheres to stringent standards, including JIS C 8201-2-1, IEC 60947-2, and EN 60947-2, assuring safe and efficient operation. Its model ID code, 2CH133, allows for easy identification, while the W90-3P front type design, compliant with GB 14048.2 standards, facilitates straightforward installation and maintenance. Weighing 900gm and manufactured in Japan, the NF125-SV features a UI rating of 690V and a UIMP of 8kV, delivering exceptional performance and protection against electrical faults. Whether for AC or DC applications, the Mitsubishi NF125-SV is a reliable choice for your electrical systems.

Key Features:

  • High Breaking Capacity: 50kA, providing robust protection against overcurrents.
  • Wide Voltage Compatibility: Suitable for use with 200V AC systems and a UI rating of 690V.
  • Compliance with Standards: Meets JIS, IEC, and EN standards for safety and performance.
  • Durable Design: Manufactured in Japan for long-lasting reliability.
  • Easy Installation: Front type design (W90-3P) for simple setup and maintenance.

Specifications:

  • Model: NF125-SV
  • Poles: 3
  • Current Rating: 100A
  • Voltage Rating: 690V
  • Breaking Capacity: 50kA
  • Standards: JIS C 8201-2-1, IEC 60947-2, EN 60947-2, GB 14048.2
  • Weight: 900gm

Ensure the safety and efficiency of your industrial or automation systems with the Mitsubishi NF125-SV circuit breaker. Its robust design and adherence to international standards make it a dependable choice for protecting your electrical infrastructure. Trust in the Mitsubishi brand for quality and performance. For all your industrial automation component needs, visit info@ramautomations.com or visit Ram Automations.
