Push Pull Actuator A1H250 Stafa Control - 250N Force

The Push Pull Actuator A1H250 from Stafa Control System is a precision-engineered component for industrial automation. Designed for demanding applications, this actuator provides reliable and efficient linear motion. With its robust construction and Swiss craftsmanship, the A1H250 ensures smooth operation and long-lasting performance in various industrial settings.

This Swiss-made actuator operates at 24V and 50Hz, delivering a maximum force of 250N with a 100mm stroke. It features an IP52 rating, protecting against dust and water ingress, and the operating temperature ranges from -20°C to 50°C. The A1H250 with its 120s response time and 3.5Va power consumption, is a top choice for automation systems, guaranteeing both efficiency and reliability. The actuator weighs 1.050 kg, making it easy to handle and install.

Key Features:

• 250N Maximum Force: Provides substantial power for various industrial tasks.
• 24V Operation: Designed for standard industrial power systems.
• 100mm Stroke Length: Offers precise linear movement for accurate control.
• IP52 Rating: Ensures protection against dust and water, suitable for diverse environments.
• Swiss Craftsmanship: Guarantees high quality and reliability.

Specifications:

• Part Number: 3842 88/09
• Operating Voltage: 24V
• Frequency: 50Hz
• Maximum Force: 250N
• Stroke Length: 100mm
• Response Time: 120s
• Power Consumption: 3.5Va
• Weight: 1.050 kg
• Temperature Range: -20°C to 50°C
• Protection: IP52

Experience the precision and reliability of the Stafa Control System A1H250 push pull actuator. Ideal for upgrading existing systems or new projects, this actuator delivers exceptional performance in industrial and automation applications. Contact Ram Automations at info@ramautomations.com for more information and enhance your automation setup today.
